Advantages.

• Passive House Institute (in Darmstadt, Germany) – Certified Component from the Passive House Institute for low-energy and Passive houses. Its high-quality thermal insulation and its technically sophisticated construction provide optimum conditions for a comfortable indoor climate.

• Outstanding door leaf thermal insulation performance: thermal transfer coefficient U-value 0.54 W/m²K door leaf (0.8 W/m²K installed).

• Resistant to burglary (PAS 24 security certified) with high specification locks, hinges and hardware.

• Steel reinforcement resulting in an ultra-stable door.

• 30 dB acoustic insulation as standard but can be upgraded to 42dB on request.

• If the door needs to be fireproof, it can be supplied as FD 30 on request.

• Slimline threshold.

• Come with a 10 year warranty if the door warps by more than 4mm.

Advantages.

• Passive House Institute (in Darmstadt, Germany) – Certified Component from the Passive House Institute for low-energy and Passive houses. Its high-quality thermal insulation and its technically sophisticated construction provide optimum conditions for a comfortable indoor climate.

• Outstanding door leaf thermal insulation performance: thermal transfer coefficient U-value 0.54 W/m²K door leaf (0.8 W/m²K installed).

• Resistant to burglary (PAS 24 security certified) with high specification locks, hinges and hardware.

• Steel reinforcement resulting in an ultra-stable door.

• 30 dB acoustic insulation as standard but can be upgraded to 42dB on request.

• If the door needs to be fireproof, it can be supplied as FD 30 on request.

• Slimline threshold.

• Come with a 10 year warranty if the door warps by more than 4mm.

Design.

Bespoke designs, from contemporary through to traditional, can be grooved on both sides of the door before being factory finished in any colour.

The door can be supplied with or without pull bar or traditional handles.

Designer vision panels can be inserted – toughened and argon filled.

 Construction.

The sandwich construction is made of laminated spruce core and of HCFC-free and environmentally friendly PU hard foam.

The specially isolated flat iron stabilizer prevents any thermal bridges and avoids condensation problems. The flat steel guarantees optimum stability and has achieved best values in all performance classes for CE marking as defined in EN 14351-1. The metal plate which absorbs tractive and shearing forces is located on the lock side, friction locked glued, thermally separated to prevent cold bridges and sound insulated.

The flexible weatherseal can resist extreme temperature changes (going from -60^oC to +250^oC).

Automatic self-locking door as an option, supplied with a 3 point lock and high security Ultion cylinder.

The rebated door leaf comes in sizes up to 2.47m high by up to 1.15m wide, with a thickness of 98mm, with the frame/opening measuring up to 2.52m high x 1.2m wide.

The door weighs only 70kg for a size of 2.24m x 1.05m x 98mm.

The Passive House door blank is CE certified (EN14351-1:2006 External Doors and Windows) and reaches best results in all mandatory aspects: wind-load resistance EN 12210, security classification WK2 (door blank resistance classification 3) ENV 1627, airtightness classification EN 12207 (class 3)…

The frames come in Oak (FSC), Meranti (FSC) or Pine (FSC). The external layer of the door comes in a natural wood veneer such as Oak, Meranti, Pine, Okume (FSC) or exterior MDF (FSC).

We offer these highest quality doors with veneer strips (with vertically aligned annual rings), laminated and finger-jointed casings in high-quality weatherproof timber.

The strong 5-ply veneer plywood face is made from carefully selected woods, glued to meet WBP weather resistance. The decorative top veneer layer meets the highest quality standards and is book-matched sliced veneer or Fineline.

Alternatively, a 3-ply cross grained veneer is fully surface bonded with the overall construction. This can be grooved to any pattern and factory finished in any colour.
